Art.-Nr.: DH-IPC-MBW4231P-AS-H-0360B

EAN: 6939554916182

Produktinformationen "2MP WDR Others Network CAMERA"

> 1/2.8” 2Megapixel progressive scan STRAVIS™ CMOS > H.265&H.264 triple-stream encoding > 50/60fps@1080(1920×1080) > WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC, > Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS > 2.8mm fixed lens (3.6mm, 6mm optional) > Max. IR LEDs Length 30m > Micro SD memory, IP67, IK10, IP6K9K, PoE > E-MARK(ECE-Regulation No.10)

Technische Daten

Function
Micro SD Card (Max.)	256 GB
Smart Event
IVS	Tripwire, Intrusion, Object Abandoned/Missing
Video
Video Compression	H.265+/H.265/H.264+/H.264
Video Frame Rate	Main Stream: 1080P(1-50/60fps); Sub Stream: D1(1-50/60fps); Third Stream: 1080P(1-25/30fps);
Streaming Capability	3 streams
Resolution	1080P(1920×1080)/1.3M(1280x960)/720P(1280×720)/D1(704×576/704×480)/VGA(640×480)/CIF(352×288/352×240)
Bit Rate Control	CBR/VBR
Video Bit Rate	H.264: 24-10240Kbps; H.265: 14-9984Kbps;
Day/Night	Auto(ICR)/Color/B/W
BLC	Yes
HLC	Yes
WDR	WDR(120dB)
White Balance	Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control	Auto/Manual
Noise Reduction	3D DNR
Motion Detection	OFF/ON (4 areas, rectangular)
Region of Interest (RoI)	Off/On (4 Zone)
Smart Illumination	Yes
Image Rotation	0°/90°/180°/270°
Mirror	Off/On
Privacy Masking	Off/On (4 Area, Rectangle)
Network
Network Port	RJ45(10/100Base-T)
Network Protocol	HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;IGMP; SNMP
Interoperability	ONVIF, PSIA, CGI
User/Host	Unicast:10 Users Multicast:20 Users
Storage	NAS Local PC for instant recording Mirco SD card 128GB
Browser	IE, Chrome, Firefox, Safari
Management Software	Smart PSS, DSS, Easy4ip
Mobile Client	iOS; Android
Port
Audio Input	1 channel
Audio Output	1 channel
Alarm Input	1 channel in: wet contact, 5 mA 3–5 VDC
Alarm Output	1 channel out: wet contact, 300 mA 12 VDC
Environment
Operating Temperature	-40° C - +70° C (-40° F - +158° F) / Less than 95% RH
Storage Temperature	-40° C - +70° C (-40° F - +158° F) / Less than 95% RH
Protection	IP67;IP6K9K;IK10
Lens
Lens Type	Fixed-focal
Lens Mount	M 12
Focal Length	3.6 mm
Max. Aperture	F 2.0
Field of View	Horizontal:87°; Vertical: 46°; Diagonal:105°;
Iris Control	Fixed
DORI Distance	Detect:55m(180ft); Observe:22m(72ft); Recognize:11m(36ft); Identify:6m(20ft);
Camera
Image Sensor	1/2.8" CMOS
Pixel	2 MP
Max. Resolution	1920 × 1080
ROM	32 MB
RAM	256 MB
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual 1/3 s-1/100,000 s
Min. Illumination	0.009Lux/F2.0( Color,1/3s,30IRE); 0.07Lux/2.0( Color,1/30s,30IRE); 0Lux/F2.0(IR on);
S/N Ratio	More than 50dB
Illumination Distance	Distance up to 30m (98ft)
Illuminator On/Off Control	Auto/Manual
Illuminator Number	2
Angle Adjustment	Pan:0˚-20˚; Tilt:±15˚; Rotation:0˚-360˚;
Structure
Casing Material	Metal
Product Dimensions	140.6 mm × 112.9 mm × 69.4 mm (5.54" × 4.44" × 2.73") (L × W × H)
Net Weight	0.59 kg (1.3 lb)
Gross Weight	0.8 kg (1.76 lb)
Certification
Certifications	CE (EN 60950:2000); UL:UL60950-1; FCC: FCC Part 15 Subpart B; E-mark(ECE-Regulation No.10); EN50155(Environment);
Power
Operating Voltage	DC12V, PoE (802.3af)(Class 0)
Power Consumption	< 6.5W
